| Product | UNIT PRICE | Delivery |
|---|---|---|
| 40358 - Diaphragm Kit Ø90 PTFE-coated EPDM | $ 250.32 | 4 - 6 Weeks |
| P/N: 10407517 MEMDOS LB260 | $ 3824.85 | 15 - 17 Weeks |
| MEMDOS LB 60 PVDF/PTFE | $ 2030.77 | 5 - 7 Weeks |
| 12601001 | $ 288.49 | 5 - 7 Weeks |
| 12601036 | $ 288.49 | 3 - 5 Weeks |
| 19999999 MEMDOS LP 60 PP/EPDM | $ 3495.08 | 5 - 7 Weeks |
| 10211405 | $ 582.43 | 5 - 7 Weeks |
| Manufacturer | Jesco |
|---|---|
| Country | |
| Part number | 10231347 |
| Inner Code | 3849556 |
| Custom Code | 84135040 |
| Technical specification | (MAGDOS LP 1 PP/EPDM Mathcode: 0102P0010BP032A1K1KP1ZP1Z00 Product: MAGDOS Type: LP Delivery rate: 0.76 l/h at 16 bar - 1.1 l/h at 8 bar Capacity adjustment: Stroke frequency adjustable: up to 250 strokes/min Material dosing head and valves: PP Control unit: 110 - 240 V +5/-10 %, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, USA (for 115 V AC) Suction valve DN3: Double-ball ceramic/PVDF/EPDM (ball/seat/gasket) Discharge Valve DN3: Double-ball ceramic/PVDF/EPDM (ball/seat/gasket) Material suction connection: PP Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PP Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Option: without Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display with multi-language menu Analogue input and pulse input (increase and reduction) Level input with early warning and main alarm Release input for external start/stop Supply amount displayed in various units Maximum delivery rate can be limited Energy-saving "Eco-mode" is available Stroke feedback output Alarm relay output Batch dosing with interval and timer functions Dosing control input Diaphragm failure input for leak monitoring Dosing quantity adjustment possible in ppm) |
|---|---|
| Weight | 3.2 |
