Looking to buy 11296 / TRIVAC D65B by Leybold in the United States? At Onrion LLC, we offer a wide range of industrial products, including 11296 / TRIVAC D65B. Whether you're located in Houston, Austin, San Antonio, Fort Worth, Dallas, Los Angeles, San Diego, Salt Lake City, Kansas City, Seattle, Miami, Detroit, New York City, Chicago, or Denver, we can supply the Leybold products you need.
11296 / TRIVAC D65B Rotary vane vacuum pump
If you need more information about 11296 / TRIVAC D65B, please contact us for details.
As an independent supplier, we provide genuine Leybold products at competitive prices. Our efficient distribution network ensures prompt delivery across the USA. We source our products from trusted channels, so you can be confident in the authenticity and quality of the items you purchase from us.
Ready to purchase or need more details about 11296 / TRIVAC D65B? Reach out to us today. Call +1 862 3004034 or email sales@enapart.com. Our expert team is here to assist you in finding the perfect solutions for your industrial needs.
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
No, we are not the authorized distributor of Leybold in the United States. However, we source our products from trusted channels to ensure you receive authentic Leybold items.
You can purchase 11296 / TRIVAC D65B by Leybold from Onrion LLC. We serve customers across the USA, offering competitive prices and reliable service.
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Onrion LLC is an independent supplier of Leybold products and is not affiliated with or authorized by the official distributor. All trademarks and brand names are the property of their respective owners.
All trademarks and brands mentioned are the property of their respective owners. We operate solely as a reseller of these products.
| Product | UNIT PRICE | Delivery |
|---|---|---|
| E6525604 | $ 294.66 | 11 - 13 Weeks |
| 230301V01 | $ 2827.29 | 11 - 13 Weeks |
| 960305 | $ 3316.29 | 5 - 7 Weeks |
| LEYBONOL LVO 100 (20L) | $ 781.71 | 9 - 11 Weeks |
| 21L1011100 / TTR91RN | $ 779.04 | 11 - 13 Weeks |
| Manufacturer | Leybold |
|---|---|
| Country | |
| Part number | 11296 / TRIVAC D65B |
| Inner Code | 31103 |
| Custom Code | 84141025 |
| Technical specification | Features: Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed, i.e. no use of elastomer Seals that can be chemically attacked. The TRIVAC B The pump has a hydropneumatic suction pipe valve for vacuum protection and via a gas ballast device with which it It is possible to pump condensable vapors. ATEX certification of the pump in accordance with EU Directive 2014/34/EU in The Equipment group II, category 3 without ATEX certified motor ATEX II 3/-G Exh IIC T4 (50Hz) Gc ATEX II 3/-G Exh IIC T3 (60Hz) Gc 12°C<Ta< 40°C As intended, the vacuum pump must not be used in an explosion operate in a hazardous environment. Engine certification: CSA, UR Pump certification: CE, ATEX 3i RoHS compliant Technical data: Suction rate in accordance with DIN 28400:65 m³/h (50 Hz)/78 m³/h (60 Hz) Final partial pressure without gas ballast: 10-4 mbar Total ultimate pressure with gas ballast: < 5·10-3 mbar Sound level in accordance with DIN 45 635 with/with gas ballast: 57/ 59 dB (A) Dimensions (LxWxH): 797 x 235 x 357 mm Oil filling min/max: 2.0/3.3 l Includes oil filling with LVO 100 Motor data: Rated power of the three-phase motor 2.2 kW Rated speed: 1460 min-1 (50 Hz)/1760 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 9.0 A/200-240 V; 60 Hz; 8.8 A 200 V; 50 Hz; 9 A (IE3 = 86.7%) 208-240 V; 60 Hz; 7.8 A (IE3 = 89.5%) 380-400 V; 50 Hz; 4.5 A/400-480 V; 60 Hz; 4.4 A 380-400 V; 50 Hz; 4.5 A (IE3 = 86.7%) 416-480 V; 60 Hz; 3.9 A (IE3 = 89.5%) Suitable for line voltages +/- 10% Suction flange: DN40KF can be used horizontally and vertically Outlet flange: DN40KF can be used horizontally and vertically Cooling: air equipment: Manual gas ballast device (on/off) Inert gas connection for the M16x1.5 gas ballast Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug Box contents: user manual spare parts list 2 x centering and clamping rings Leybonol LVO 100 oil filling Recommended accessories: OF 40-65 or CF 40-65 are main flow oil filter devices that also can be attached to the pump retroactively. The Indians TRIVAC B built-in oil pump draws in the oil and pumps it through the oil filter device, only then does the purified oil reach the Lubricate the pump. This is how the oil filter device does not extend only the oil life, but also the life of the pump |
|---|---|
| Weight | 84.5 |
