Product | UNIT PRICE | Delivery |
---|---|---|
PTFE6-110-991745 | $ 6902.08 | 8 - 10 Weeks |
BZP004F-095RDG51R / P-TF4-95RDG | $ 5814.38 | 9 - 11 Weeks |
ASF3-50GD-161217L | $ 4481.54 | 12 - 14 Weeks |
P/N: BZP053032RD--165R, Type: SF3/32RD-O | $ 2516.12 | 7 - 9 Weeks |
Manufacturer | Steimel |
---|---|
Country | |
Part number | ASF2-20RD-170734R |
Inner Code | 3825672 |
Custom Code | 84136039 |
Technical specification | A-SF2/20RD-VLFM, pump unit, 2-20 bar 1.1 kW, 1000, 230/400 V, 50 Hz, IP55, Iso.F, B5, IE3 Gear pump unit: SF 2/20 RD - VLFM Product no.: ASF2-20RD-170734R Dimension sheet: DPA052D-170734R Spare part list: DET052020RD--165R Suction and pressure connection: G 1/SAE 1 Case parts: EN-GJL-250 (GG-25) Sprocket shafts, noiseless: 16MnCrS5, egh. , obliquely toothed Storage: multi-layer Shaft seal: radial shaft seal Elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: 18/21.6 l/min. Pressure: 5 bar Speed: 950/1140 rpm. pressure relief valve Setting range: 2-20 bar Opening pressure: 8 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Pump support with foot: BLF052200110LA21 Three-phase motor: LDM090-06-095 (Birkenbeul) Motor data: Power: 1.1 kW Speed: 1000/ 1200 rpm Voltage/frequency: 230/400 volts at 50 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Additional sign (without IE3) for: Voltage/frequency: 220-240/380-420 V at 50/60 Hz 250-280/440-480 V at 60 Hz Design: B 5 Aggregate coating: none Identification plate: ETY924-D/E--PE02 Motor terminal box rotated 90° to the suction side |
---|---|
Weight | 30 |
