Product | UNIT PRICE | Delivery |
---|---|---|
00.0002.5595 | $ 243.24 | 3 - 5 Weeks |
707XX469 | $ 2846.53 | 5 - 7 Weeks |
704XX874 | $ 3138.03 | 6 - 8 Weeks |
CV- 020G.PSO.R | $ 196.81 | 5 - 7 Weeks |
00.0002.A750.1 / Type S1.S29.3.0085.S.25GO.TRJ.I1.1,0M.60 | $ 237.28 | 6 - 8 Weeks |
Manufacturer | Valco |
---|---|
Country | |
Part number | 00.0002.9543 |
Inner Code | 4737967 |
Technical specification | Explosion-proof level control - Contacts #2 Certification: ATEX ex-DB and EAC TR-CU (Former Gost-R) Construction with black anodized aluminum sink, ex-DB II 1/2G IIC = 9 Max working temperature 160°C = T6/T5, see attached table Mod. M2.EA52L.4.0700.EA.FEAWJ.E19J2.I12.660.420 S52L type float - AISI 316 material AISI 316 tephoned rod Flange connection Ø 100 mm./6 holes - AISI-303 material Viton seal material Max working pressure 40 bar Total length L0 = 700 mm. Intervention rates in mm and contact situations in the absence of a level: L1 = 660 = NA L2 = 420 = NC Contact wiring = separate Max. electrical load : Type 4 contact = 250VAC/80VA/1.3A - 250Vcc/80W/1.3A Type E1 electrical output: Aluminum die-cast case with epoxy coating ¾” NPT-F cable entry Degree of protection IP67 |
---|---|
Weight | 1.5 |
